Omron M1 Series User Manual

Power
supply
voltage
Standard appli-
cable motor (kW)
Inverter model
HHD/HD/HND/N
D mode
Semiconductor protection fuse
product number, manufacturer:
Mersen / Bussmann (Eaton)
Three-
phase 400
V
0.4 3G3M1-A4004 HHD PC30UD69V50□/170M3458
0.75 3G3M1-A4004
HD/HND
3G3M1-A4004 ND
3G3M1-A4007 HHD PC30UD69V50□/170M3458
1.1 3G3M1-A4007 HD/HND
1.5 3G3M1-A4007 ND
3G3M1-A4015 HHD PC30UD69V50□/170M3459
2.2 3G3M1-A4015 HD/HND
3G3M1-A4015 ND
3G3M1-A4022 HHD PC30UD69V63□/170M3460
3 3G3M1-A4022 HD/HND
3G3M1-A4022 ND
3.7 3G3M1-A4040 HHD PC30UD69V63□/170M3461
5.5 3G3M1-A4040 HD/HND
3G3M1-A4040 ND
3G3M1-A4055 HHD PC30UD69V100□/170M3462
7.5 3G3M1-A4055 HD/HND
3G3M1-A4075 HHD PC30UD69V100□/170M3462
11 3G3M1-A4075 ND PC30UD69V100□/170M3462
3G3M1-A4075 HD/HND PC30UD69V100□/170M3462
3G3M1-A4110 HHD PC30UD69V125□/170M3463
15 3G3M1-A4075 ND PC30UD69V100□/170M3462
3G3M1-A4110 HD/HND PC30UD69V125□/170M3463
3G3M1-A4150 HHD PC30UD69V160□/170M3464
18.5 3G3M1-A4110 ND PC30UD69V125□/170M3463
3G3M1-A4150 HD/HND PC30UD69V160□/170M3464
3G3M1-A4185 HHD PC30UD69V160□/170M3464
22 3G3M1-A4150 ND PC30UD69V160□/170M3464
3G3M1-A4185 HD/HND PC30UD69V160□/170M3464
3G3M1-A4220 HHD PC30UD69V200□/170M3465
30 3G3M1-A4185 ND PC30UD69V160□/170M3464
3G3M1-A4220 HD/HND PC30UD69V200□/170M3465
37 3G3M1-A4220 ND
2 Design
2-83
M1 Series Standard Type User's Manual (I669)
2-4 Others
2
2-4-3 UL/cUL Standards Cautions

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
