Omron M1 Series User Manual

Fuse Size
Power
supply
voltage
Standard appli-
cable motor (kW)
Inverter model
HHD/HD/HND/N
D mode
Semiconductor protection fuse
product number, manufacturer:
Mersen / Bussmann (Eaton)
Three-
phase 200
V
0.1 3G3M1-A2001 HHD PC30UD69V50□/170M3458
0.2 3G3M1-A2001
HND
3G3M1-A2002 HHD PC30UD69V50□/170M3458
0.4 3G3M1-A2002 HND
3G3M1-A2004 HHD PC30UD69V50□/170M3458
0.75 3G3M1-A2004 HND
3G3M1-A2007 HHD PC30UD69V50□/170M3460
1.1 3G3M1-A2007 HND
1.5 3G3M1-A2015 HHD PC30UD69V80□/170M3462
2.2 3G3M1-A2015 HND
3G3M1-A2022 HHD PC30UD69V125□/170M3462
3 3G3M1-A2022 HND
3.7 3G3M1-A2037 HHD PC30UD69V125□/170M3463
5.5 3G3M1-A2037 HND
3G3M1-A2055 HHD PC30UD69V160□/170M3464
7.5 3G3M1-A2055 HND
3G3M1-A2075 HHD PC30UD69V200□/170M3465
11 3G3M1-A2075 HND
3G3M1-A2110 HHD PC30UD69V200□/170M3465
15 3G3M1-A2110 HND
3G3M1-A2150 HHD PC30UD69V250□/170M3466
18.5 3G3M1-A2150 HND
3G3M1-A2185 HHD PC30UD69V250□/170M3466
22 3G3M1-A2185 HND
2 Design
2-82
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
