Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit
W07 Output Torque Monitor
-999 to 999
0 - %
W08 Rotate Speed Monitor
0.00 to 99990
0 - r/min
W09 Load Shaft Speed
0.00 to 99990
0 - r/min
W10 Feed Speed
0.00 to 99990
0 - m/min
W11 PID Process Command
-999.00 to 9990.00
0 - -
W12 PID Feedback Value Monitor
-999.00 to 9990.00
0 - -
W13
Analog Torque Limit Value Moni-
tor
-300 to 300 %
300 - %
W14 Do not use - - - -
W15 Ratio value Monitor
0.00 to 200.00
0 - %
W16 Motor Speed Set Value
0.00 to 99990
0 - r/min
W17 Load Shaft Set Value
0.00 to 99990
0 - r/min
W18 Feed Speed Set Value
0.00 to 99990
0 - m/min
W19
Transport Time Set Value for
Specified Length
0.00 to 99990 min
999.9 - min
4 Parameter List
4-31
M1 Series Standard Type User's Manual (I669)
4-1 List of Monitors by Group
4
4-1-2 Parameter W (Monitor 2)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
