Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit
W147 Position Deviation Monitor (LSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
W148
Touch Probe 1 Positive Edge
(MSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
W149
Touch Probe 1 Positive Edge
(LSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
W150
Touch Probe 2 Positive Edge
(MSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
W151
Touch Probe 2 Positive Edge
(LSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
W152 Touch Probe Status
Bit15: ---
Bit14: ---
Bit13: ---
Bit12: ---
Bit11: ---
Bit10: ---
Bit9: Touch probe 2 PLc
Bit8: T
ouch probe 2 Enb
Bit7: ---
Bit6: ---
Bit5: ---
Bit4: ---
Bit3: ---
Bit2: ---
Bit1: Touch probe 1 PLc
Bit0: Touch probe 1 Enb
0 - -
4 Parameter List
4-39
M1 Series Standard Type User's Manual (I669)
4-1 List of Monitors by Group
4
4-1-2 Parameter W (Monitor 2)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
