Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit
W136
Input Terminal [AI1] Input Voltage
(AIV)
-1024 to 1023
(1023 ＝ 10.9V)
0 - -
W137
Input Terminal [AI2] Input Current
(AII)
0 to 1023
(1023 ＝ 23.3mA)
0 - -
W138
Input Terminal [AI2] Input Voltage
(AIV)
0 to 1023
(1023 ＝ 10.9V)
0 - -
W139 Pulse Train Frequency Monitor
-163.84 to 163.83 %
0 - %
W142
Feedback Current Position Moni-
tor (MSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
W143
Feedback Current Position Moni-
tor (LSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
W144 Target Position Monitor (MSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
W145 Target Position Monitor (LSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
W146 Position Deviation Monitor (MSB)
−268435455 to 268435455
(MSB: -4096 to 4095, LSB: 0
to 65535)
0 - -
