Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
P04
1st Auto Tuning
Function Selection
0: Disable
1: Tune the motor parameters
while stopped
2: Tune the motor parameters
while rotating
4: T
une the PM motor magnet-
ic pole position offset while ro-
tating
5: Tune the motor %R1 and
%X while stopped
0 - -
page
6-65
P05
1st Online Tuning
Function Selection
0: Disable
1: Enable
0
Availa-
ble
-
page
6-71
P06
1st Motor Armature
Resistance
0.00 to 500.0 A
10.55 - A
page
6-6
P07
1st Motor Parameter
%R1
0.00 to 50.00 %
3.17
Availa-
ble
%
page
6-65
P08
1st Motor Parameter
%X
0.00 to 50.00 %
11.47
Availa-
ble
%
page
6-65
P09
1st Slip Compensation
Gain for Driving
0.0 to 200.0 %
100.0
Availa-
ble
%
page
5-16
P10
1st Slip Compensation
Response T
ime
0.01 to 10.00 s
0.12
Availa-
ble
s
page
5-16
P11
1st Slip Compensation
Gain for Braking
0.0 to 200.0 %
100.0
Availa-
ble
%
page
5-16
P12
1st Rated Slip Fre-
quency
0.00 to 15.00 Hz
1 - Hz
page
5-16
P13 1st Iron Loss Factor 1
0.00 to 20.00 %
2.86
Availa-
ble
%
page
6-6
4 Parameter List
4-113
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-4 Parameter P (Motor 1 Parameter)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
