Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
H185 Do not use - - - - -
H193
User Preference Data-
set Registration
0: Disable
1: Store
0 - -
page
5-4
H194
User Preference Data-
set Protection Func-
tion Selection
0: Unprotected
1: Protected
0
Availa-
ble
-
page
5-4
H195
DC Injection Braking
Startup Time
0.00: Disable
0.01 to 30.00 s
Only motor 1 is ef
fective
0
A
vaila-
ble
s
page
7-63
H196
Do not use - - - - -
H197
User password 1
Mode selection
0: Display all, but prevent
changes
1: Display and allow changes
in quick-setup only
2: Do not use
0
Availa-
ble
-
page
7-77
H198
User Password 1 Set-
ting/Verification
0000 to FFFF Hex
0
Availa-
ble
-
page
7-77
H199
User Password 1 Set-
ting
0: Disable
1: Protected
0
Availa-
ble
-
page
7-77
H303
Co-Inverter Communi-
cation Function Selec-
tion
0: Disable
1: Enable
2: Enable (administrator)
0 - -
page
8-28
H304
Co-inverter Communi-
cation Starting Station
Number (Administra-
tor)
1 to 8
Need to be set in administra-
tor(H303=2)
1 - -
page
8-28
4 Parameter List
4-125
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-5 Parameter H (High Level Functions)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
