Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
H317
Logical Expression 1
Logical Operator
0: AND
1: OR
2: XOR
0 - -
page
7-94
H318
Logical Expression 2
Operation Target 1
Refer to other sheet
27,100,206,207,208 Can't be
selected
0 - -
page
7-94
H319
Logical Expression 2
Operation Target 2
Refer to other sheet
27,100,206,207,208 Can't be
selected
0 - -
page
7-94
H320
Logical Expression 2
Logical Operator
0: AND
1: OR
2: XOR
0 - -
page
7-94
H321
Logical Expression 3
Operation Target 1
Refer to other sheet
27,100,206,207,208 Can't be
selected
0 - -
page
7-94
H322
Logical Expression 3
Operation Target 2
Refer to other sheet
27,100,206,207,208 Can't be
selected
0 - -
page
7-94
H323
Logical Expression 3
Logical Operator
0: AND
1: OR
2: XOR
0 - -
page
7-94
H324
Input Terminal [DI1]
Response Time
1 to 400 ms
1 - ms
page
5-51
H325
Input Terminal [DI2]
Response Time
1 to 400 ms
1 - ms
page
5-51
4 Parameter List
4-127
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-5 Parameter H (High Level Functions)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
