Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
A04
2nd Rated Voltage at
Maximum Output Fre-
quency
80 to 240 V: AVR operation
(200 V class series)
160 to 500 V: AVR operation
(400 V class series)
200
- V
page
5-19
A05
2nd Manual Torque
Boost Voltage
0.0 to 20.0 %
Percentage with respect to
2nd rated voltage at base fre-
quency (A003)
1.9
Availa-
ble
%
page
5-73
A06
2nd Motor Electronic
Thermal Characteristic
selection
1: For a general-purpose mo-
tor with shaft-driven cooling
fan
2: For an inverter-driven motor
non-ventilated motor or motor
with separately powered cool-
ing fan
1
Availa-
ble
-
page
5-20
A07
2nd Motor Electronic
Thermal Level
0.00 ; 0.01 to 118.8
0.00 : Disable
0.01 to 118.8 A
* Setting range from 1%(HHD)
to 135%(ND) of the rated in-
verter current.
21
Availa-
ble
A
page
5-20
A08
2nd Motor Electronic
Thermal Time Con-
stant
0.5 to 75.0 min
5
Availa-
ble
min
page
5-20
A09
2nd DC Injection Brak-
ing Start Frequency
0.0 to 60.0 Hz
0.0
Availa-
ble
Hz
page
7-63
A10
2nd DC Injection Brak-
ing Level
0 to 100% (HHD mode)
0 to 80% (HND/HD mode)
0 to 60% (ND mode)
Based on inverter rated cur-
rent
0
Availa-
ble
%
page
7-63
4 Parameter List
4-136
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
