Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
A11
2nd DC Injection Brak-
ing T
ime
0.00: Disable
0.01 to 30.00 s
0.00
Availa-
ble
s
page
7-63
A12
2nd Starting Frequen-
cy
0.0 to 60.0 Hz
0.5
Availa-
ble
Hz
page
7-114
A13
2nd V/f Characteristics
Selection
0: Variable torque load
1: Constant torque load
1 - -
page
5-10
A14
2nd Drive Control Se-
lection
0: IM V/f control
1: IM Dynamic torque vector
control without speed sensor
3: IM V/f control with speed
sensor
4: IM Dynamic torque vector
control with speed sensor
5: IM Vector control without
speed sensor
6: IM Vector control with speed
sensor
0
- -
page
5-10
page
6-16
page
6-11
page
6-21
A15
2nd Motor Pole Num-
ber
2 to 128 poles
4 - Pole
page
5-19
A16 2nd Motor Capacity
0.01 to 1000 kW
5.50 - kW
page
5-19
A17
2nd Motor Rated Cur-
rent
0.00 to 2000 A
21 - A
page
6-4
A18
2nd Auto-tuning Se-
lection Function Selec-
tion
0: Disable
1: Tune the motor parameters
while stopped
2: Tune the motor parameters
while rotating
5: T
une the motor %R1 and
%X while stopped
0 - -
page
6-65
4 Parameter List
4-137
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-6 Parameter A (Motor 2 Parameter)
To Next Page
