Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
J91
Overload Stop Func-
tion Integral time
0.001 to 9.999 s
999: 0.025 s
32767
Availa-
ble
s
page
7-153
J92
Overload Stop Func-
tion Current level
50.0% to 150.0%
100
Availa-
ble
%
page
7-153
J95
Brake control Brake-
release Torque
0.00 to 300.00 %
100
Availa-
ble
%
page
6-76
J96
Brake Control Opera-
tion Selection
Bit6: Stop condition at Position
control
0: BRK OFF
1: BRK ON
Bit4: Brake-applied condition
0: Disable RUN command
"OFF"
1: Enable RUN command
"OFF"
Bit3 to 1: Reserved
Bit0: Speed detection/Speed
command
0: Speed detection
1: Speed command
0
Availa-
ble
-
page
6-76
J97 Servo Lock Gain
0.000 to 9.999
0.01
Availa-
ble
-
page
7-148
J98
Servo Lock Comple-
tion Timer
0.000 to 1.000 s
0.1
Availa-
ble
s
page
7-148
J99
Servo Lock Comple-
tion Range
0 to 9999
10
Availa-
ble
-
page
7-148
J105 Do not use - - - - -
J106
PID Control Maximum
Scale
-999.00 to 0.00 to 9990.00
100 - -
page
7-123
J107
PID Control Minimum
Scale
-999.00 to 0.00 to 9990.00
0 - -
page
7-123
4 Parameter List
4-147
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-9 Parameter J (Applied Functions 1)
