Omron M1 Series User Manual

Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
d223
Detection Level of Ex-
cessive Positioning
Deviation (MSB)
0: Disable (MSB: 0, LSB: 0)
1 to 268435455 (MSB: 0 to
4,095, LSB: 0 to 65,535)
0
Availa-
ble
-
page
6-61
d224
Detection Level of Ex-
cessive Positioning
Deviation (LSB)
0: Disable (MSB: 0, LSB: 0)
1 to 268435455 (MSB: 0 to
4,095, LSB: 0 to 65,535)
0
Availa-
ble
-
page
6-61
d225
Software Overtravel
Detection Position in
the Positive Direction
(MSB)
−268435455 to 268435455
(MSB: -4,096 to 4,095, LSB: 0
to 65,535)
4095 - -
page
6-43
d226
Software Overtravel
Detection Position in
the Positive Direction
(LSB)
−268435455 to 268435455
(MSB: -4,096 to 4,095, LSB: 0
to 65,535)
65535 - -
page
6-43
d227
Software Overtravel
Detection Position in
the Negative Direction
(MSB)
−268435455 to 268435455
(MSB: -4,096 to 4,095, LSB: 0
to 65,535)
-4096 - -
page
6-43
d228
Software Overtravel
Detection Position in
the Negative Direction
(LSB)
−268435455 to 268435455
(MSB: -4,096 to 4,095, LSB: 0
to 65,535)
1 - -
page
6-43
d237 Positioning Data Type
0: Absolute position (ABS)
1: Relative position (INC)
0
Availa-
ble
-
page
6-49
d238
Position Data Determi-
nation Time
0.000 to 0.100 s
0.000
Availa-
ble
s
page
6-49
d239
Positioning Completed
Range
0 to 9999
1
Availa-
ble
-
page
6-49
page
6-58
4 Parameter List
4-155
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-10 Parameter d (Applied Functions 2)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
