Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
S02 Torque Reference
-327.68 to 327.67 %
0
Availa-
ble
%
page
6-31
S03
Torque Current Com-
mand
-327.68 to 327.67 %
0
Availa-
ble
%
page
6-31
S05 Frequency Reference
0.00 to 655.35 Hz
0
Availa-
ble
Hz
page
5-27
S06 Input Terminal Monitor
Bit15: RST
Bit14: DI7
Bit13: DI6
Bit12: ---
Bit11: ---
Bit10: ---
Bit9: ---
Bit8: ---
Bit7: ---
Bit6: DI5
Bit5: DI4
Bit4: DI3
Bit3: DI2
Bit2: DI1
Bit1: REV
Bit0: FWD
0
Availa-
ble
-
page
5-25
page
5-49
page
7-26
S07
Communication Data
Terminal [DO]
Bit15: ---
Bit14: ---
Bit13: ---
Bit12: ---
Bit11: ---
Bit10: ---
Bit9: ---
Bit8: RO
Bit7: ---
Bit6: ---
Bit5: ---
Bit4: ---
Bit3: ---
Bit2: ---
Bit1: DO2
Bit0: DO1
0
Availa-
ble
-
page
7-155
4 Parameter List
4-162
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
