Page #336 background imageLoading...
Page #336 background image
1st PM Motor Induced Voltage Ke (P63)
1st PM Motor Iron Loss (P64)
1st PM Motor Reference Current for Magnetic Pole Detection (P87)
1st PM Motor Overcurrent Protection Level (P90)
Auto Search Delay Time 2 for Starting Mode (H46)
Magnetic Flux Level during Deceleration (d90)
Initialize Motor 2 Parameters (H03 = 3)
When “3: Initialize motor 2 parameters” is set to Data Initialization (H03), the following parameters
are set to their default data (values at the time of shipment from the factory).
2nd Manual Torque Boost Voltage (A05)
2nd Motor Electronic Thermal Level (A07)
2nd Motor Pole Number (A15)
2nd Motor Rated Current (A17)
2nd Motor Armature Resistance (A20)
2nd Motor Motor Constant %R1 (A21)
2nd Motor Motor Constant %X (A22)
2nd Slip Compensation Gain for Braking (A25)
2nd Rated Slip Frequency (A26)
2nd Iron Loss Factor 1 (A27)
2nd Magnetic Saturation Factor 1 (A30)
2nd Magnetic Saturation Factor 2 (A31)
2nd Magnetic Saturation Factor 3 (A32)
2nd Magnetic Saturation Factor 4 (A33)
2nd Magnetic Saturation Factor 5 (A34)
T
orque Current for 2nd Vector Control (A55)
Induced Voltage Factor for 2nd Vector Control (A56)
Restore User Defined Data (H03 = 4)
When “4: Restore user defined data” is set to Data Initialization (H03), parameters are initialized us-
ing the user preference dataset saved at User Preference Dataset Registration (H193). When there
are no user preference dataset, parameters are initialized using factory defaults. (Same operation
as when Data Initialization (H03) is set to 1).
User preference dataset saved by User Preference Dataset Registration (H193) are not initialized.
(Refer to 5-1-3 User Preference Dataset (Registration/Protection) on page
5-8.)
The following parameters are not initialized.
Main Circuit Capacitor Service Life Coefficient (Measurement Value) (H42)
Main Circuit Capacitor Service Life Coefficient (Initial Value) (H47)
Service Life of Main Circuit Capacitor Remaining Time (H77)
Cumulative Run Time of Cooling Fan (H43)
Cumulative Run Time of Capacitors on Printed Circuit Boards (H48)
1st Startup Count for Motor (H44)
2nd Startup Counter for Motor (A52)
5 Basic Settings
5-6
M1 Series Standard Type User's Manual (I669)
