Set the following constants according to the settings of 1st Drive Control Selection (F42)/2nd Drive
Control Selection (A14).
Dynamic Torque Vector Control (With/without Speed Sensor) (In-
duction Motor)
Parameter
No.
Function name Set data Default data
F42/A14
1st Drive Control Selection/2nd
Drive Control Selection
1: IM Dynamic torque vector control
5: IM Vector control without speed sensor
0
F04/A02
1st Base Frequency/2nd Base
Frequency
Motor rated value
50.0 Hz
F05/A03
1st Rated Voltage at Base Fre-
quency/2nd Rated Voltage at
Base Frequency
Dependent on
capacity
P02/A16
1st Motor Capacity/2nd Motor
Capacity
Dependent on
capacity
P03/A17
1st Motor Rated Current/2nd
Motor Rated Current
Dependent on
capacity
P06/A20
1st Motor Armature
Resistance/2nd Motor Armature
Resistance
When rotation tuning can be performed,
this does not need to be set.
When rotation tuning is not possible, either
set the values given in the test report for
the motor
, or set the value calculated by
the following formula.
Dependent on
capacity
F03/A01
1st Maximum Output Frequen-
cy/2nd Maximum Output Fre-
quency
Design specification value
60.0 Hz
F07 1st Acceleration Time 1 6.0 s
F08 1st Deceleration Time 1 6.0 s
Vector Control (With/without Speed Sensor) (Induction Motor)
Parameter
No.
Function name Set data Default data
F42/A14
1st Drive Control Selection/2nd
Drive Control Selection
4: IM Dynamic torque vector control with
speed sensor
6: IM Vector control with speed sensor
0
6 Vector Control and Applied Functions
6-7
M1 Series Standard Type User's Manual (I669)
6-1 Details of Motor Control Methods
6
6-1-3 Motor Parameter Settings
