Omron M1 Series User Manual

Parameter
No.
Function name Set data Default data
F04/A02
1st Base Frequency/2nd Base
Frequency
Motor rated value
50.0 Hz
F05/A03
1st Rated Voltage at Base Fre-
quency/2nd Rated V
oltage at
Base Frequency
Dependent on
capacity
P01/A15
1st Motor Pole Number/2nd
Motor Pole Number
4
P02/A16
1st Motor Capacity/2nd Motor
Capacity
Dependent on
capacity
P03/A17
1st Motor Rated Current/2nd
Motor Rated Current
Dependent on
capacity
P06/A20
1st Motor Armature
Resistance/2nd Motor Armature
Resistance
When rotation tuning can be performed,
this does not need to be set.
When rotation tuning is not possible, either
set the values given in the test report for
the motor
, or set the value calculated by
the following formula.
(P03)
2
-(P55)
2
Dependent on
capacity
F03/A01
1st Maximum Output Frequen-
cy/2nd Maximum Output Fre-
quency
Design specification value
60.0 Hz
F07 1st Acceleration Time 1 6.0 s
F08 1st Deceleration Time 1 6.0 s
Vector Control (With/without Speed Sensor) (Synchronous Motor)
Parameter
No.
Function name Set data Default data
F42 1st Drive Control Selection
15: PM Vector control without speed and
pole position sensor
16: PM Vector control with speed and pole
position sensor
0
F26 Carrier Frequency Motor specification 2 kHz
F04
1st Base Frequency
Motor rated value
50.0 Hz
F05
1st Rated Voltage at Base Fre-
quency
Dependent on
capacity
P01 1st Motor Pole Number 4
P02 1st Motor Capacity
Dependent on
capacity
P03 1st Motor Rated Current
Dependent on
capacity
6 Vector Control and Applied Functions
6-8
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
