When this terminal is reset, the torque limit setting is disabled and the inverter uses the maximum
value (300%) as the torque limit value.
When the torque limit enabled (TL) function is not allocated to a multifunction input terminal, the tor-
que limit function is enabled at all times.
• The torque limit function regards the motor rated torque as 100%.
• When “132: TRQ (T
orque limited)” is set to Output Terminal [DO1] Function Selection (E20), Output
Terminal [DO2] Function Selection (E21) or Output Terminal [ROA, ROB] Function Selection (E27),
the torque limit function can be checked to see if it is activated by the status of the torque limited
signal.
• To enable the torque limit value by analog input or current input, set “7: Analog torque limiter” to one
of Input Terminal [AI1] Function Selection (E61), Input Terminal [AI2] Function Selection（AII）
(E62) or Input Terminal [AI2] Function Selection（AIV） (E63). Analog inputs 0 to 10 V or 4 to 20
mA (0 to 20 mA) are equivalent to torque limit values 0% to 300%. The torque limit value set by
analog input is enabled in all operation modes.
Parameter No. Function name Data
Default da-
ta
Unit
F40
Torque Limit 1 (power
running)
0 to 300 (In four quadrants, for-
ward driving)
300 %
F41
Torque Limit 2 (regenera-
tion)
0 to 300 (In four quadrants, re-
verse regeneration)
E16
Torque Limit 3 (power
running)
0 to 300 (In four quadrants, re-
verse driving)
E17
Torque Limit 4 (regenera-
tion)
0 to 300 (In four quadrants, for-
ward regeneration)
E01 to E05, E98,
E99
Input Terminal [DI1]
Function Selection to In-
put T
erminal [DI7] Func-
tion Selection
14: TRQ1 (Torque limit switching
1)
- -
184: TL (T
orque control ena-
bled)
185: TRQ2 (Torque limit switch-
ing 2)
E20, E21
Output Terminal [DO1]
Function Selection, Out-
put Terminal [DO2] Func-
tion Selection
132: TRQ (Torque limited) - -
E27
Output T
erminal [ROA,
ROB] Function Selection
E61
E62
E63
Input Terminal [AI1]
Function Selection
7: Analog torque limiter - -
Input Terminal [AI2]
Function Selection
（AII）
Input Terminal [AI2]
Function Selection
（AIV）
H74
Torque Limit Function
Selection
0: Torque limit
1: Torque current limit
1 -
H75
Torque Limit Operation
Selection
0: Four quadrants independent
0 -
1: Four quadrants identical
H76
Frequency Rising Limit
for Torque Limit
0.0 to 590.0 5.0 Hz
6 Vector Control and Applied Functions
6-82
M1 Series Standard Type User's Manual (I669)
