Item No.
Parame-
ter No.
Item Range Display item
3_06 - Operation direction
The output operation direction is
displayed. “F: Forward” or “r: Re-
verse" is displayed, and “---” is
displayed when stopped.
The rotation direction is deter-
mined according to the polarity of
the output frequency. During vec-
tor control, it is determined ac-
cording to the detection speed.
*Generally, as seen from the axial
direction, the forward rotation of
the motor is in the counterclock-
wise direction.
3_07
W01
Running Status 1
Monitor
0000Hex to FFFFHex
The operation status is displayed
by a four-digit hexadecimal.
0000 to FFFF hex
Bit15: BUSY (During Parameter
code data writing)
Bit14: -
Bit13: -
Bit12: RL (Communications effec-
tive)
Bit11: ALM (Alarm relay)
Bit10: DEC (During deceleration)
Bit9: ACC (During acceleration)
Bit8: IL (During current limiting)
Bit7: VL (During voltage limiting)
Bit6: TL (T
orque limiting)
Bit5: NUV (Main circuit DC volt-
age established)
Bit4: BRK (During braking)
Bit3: INT (Inverter shut down)
Bit2: EXT (During DC braking or
during pre-exciting)
Bit1: REV (During reverse opera-
tion)
Bit0: FWD (During forward opera-
tion)
7 Other Functions
7-4
M1 Series Standard Type User's Manual (I669)
