Item No.
Pa-
rame-
ter
No.
Item Range Display item
5_06 W67
Cumulative Run Time
of Capacitors on
Printed Circuit
Boards
0 to 9999 [x10h]
The time obtained by multiplying the coeffi-
cient based on the ambient temperature con-
ditions with the cumulative time during which
voltage is applied to the electrolytic capaci-
tors on printed circuit boards is displayed as
the cumulative operation time.
Measurement range: 0 to 99,990 hours
Display: 0 to 9999 x10 LED lit
(Cumulative run time of capacitors on printed
circuit boards = Display × 10 hours)
If 99,990 hours is exceeded, the accumula-
tion operation stops, and the display remains
as 9999.
For details, refer to 7-8-10 Capacitor Life
Warning Signal (WAC) on page 7-
96.
5_07 W68
Cumulative Run Time
of Cooling Fan
0 to 9999 [x10h]
The cumulative time when the cooling fan
was operating is displayed.
Counting is not performed when the ON/OFF
control effective (parameter H06) is enabled,
and the cooling fan has stopped.
Measurement range: 0 to 99,990 hours
Display: 0 to 9999 x10 LED lit
(Cumulative run time of cooling fan = Display
× 10 hours)
If 99,990 hours is exceeded, the accumula-
tion operation stops, and the display remains
as 9999.
5_08 W78
Number of Startups
0 to 9999
1000 to 6553 [x10
LED]
The number of operations of the 1st motor
(number of times the RUN command for the
inverter is turned ON) is calculated and dis-
played. If the number of operations becomes
10,000 or more, the x10 LED lights up and
the value of “Number of operations/10” is dis-
played. If 65,530 operations is exceeded, the
value returns to 0 and the calculation contin-
ues.
5_09 W81
Integrated Power
Monitor
0.000 to 9999
[100 kWh]
The integrating electric power consumption is
displayed. 0.1 kWh to 999,900 kWh is dis-
played for 0.001 to 9999, with 1 = 100 kWh.
The value returns to 0 at 1,000,000 kWh.
The integrated electric power consumption
and the integrated electric power data can be
reset by setting Display Coefficient for Inte-
grated Power (E51) to “0.000.” If 999,900
kWh is exceeded, the value returns to 0. Inte-
gration is not performed when 0.000 is still
set.
7 Other Functions
7-14
M1 Series Standard Type User's Manual (I669)
