Item
No.
Parameter
No.
Item Range Description
6_06 X159
Fifth Last Alarm Info.
Running Status
0000Hex to
FFFFHex
The operation status is displayed by a
four-digit hexadecimal.
6_07 X153
Fifth Last Alarm Info.
Cumulative Ope.
T
ime
0 to 655,350 hours
The number of operations of the motor
(number of times the RUN command for
the inverter is turned ON) is calculated
and displayed.
6_09 X154
Fifth last Alarm Info.
Main Circuit DC Volt-
age
0.0 to 999.0 [V]
The Main Circuit DC Voltage of the inver-
ter is displayed.
6_30
X158
Fifth last Alarm Info.
Cumulative Running
time
0 to 655,350 hours
The cumulative time of the inverter RUN
state is displayed.
The cumulative operation time is dis-
played alternately in the upper digits and
lower digits.
When the lower three digits are dis-
played, an h (hours) is displayed in the
lowermost digit.
Running Status 3 Monitor [6_24]
The operation status 3 displays the status allocated to each bit by a four-digit hexadecimal.
The allocation for 0 to 15 bits of the operation status is described in the table below.
Bit Symbol Description
15 - Fixed to 0
14 ID2 Current detection 2
13 IDL Low current detection
12 ID Current detection
11 OLP During active drive
10 LIFE Life warning
9 OH Heat sink overheat early warning
8 TRY During retry
7 FAN Fan operation signal
6 KP During touch panel operation
5 OL Motor overload early warning
4 IPF During restart after instantaneous power failure
3 SWM2 Motor 2 selection
2 RDY During operation preparation
1 FDT Frequency detection
0 FAR Frequency arrival
7 Other Functions
7-25
M1 Series Standard Type User's Manual (I669)
7-1 Status Monitors
7
7-1-4 Alarm information
