Function Command setting E61, E62, E63 data Reference
PID command
PID Control PID Command Selection
(J02) =
“1: Analog input (terminals AI1, AI2 (AII),
AI2 (AIV))”
3: PID command page 7-123
PID feedback
PID Control Feedback Selection (E119)
=
“0: Analog input terminals (AI1, AI2 (AII
function), AI2 (AIV function))”
5: PID feedback page 7-123
7-3-2
Analog Input Adjustment Function
This function adjusts the offset, bias and gain of the analog input terminals [AI1] and [AI2].
• The analog input terminal AI has a voltage input only. AI2 can be switched between current and volt-
age by Analog input selector switch (SW5).
•
Select the polarity (C35, C40, C45) of the analog signal to input and set the input range of the ana-
log signal.
• Add the values set at offsets (C31, C36, C41) to the analog input values of each terminal, and adjust
for shift of the offsets.
• Set the bias (command) (C55, C61, C67) and gain (command) (C34, C37, C42), and convert the
analog signal to digital value and adjust the resulting signal. Adjust the base point of bias (com-
mand) and gain (command) at bias (analog input) (C56, C62, C68) and gain (analog input) (C35,
C38, C43).
• Filters (C33, C38, C43) can be set to remove noise.
Param-
eter
No.
Function name Data Default data Unit
Input terminal [AI1] settings
C35
Input Terminal [AI1] Polarity Selec-
tion
0: Bipolar (-10 to 10 V)
1: Unipolar (0 to 10 V)
*1
1 -
C31 Input Terminal [AI1] Offset -5.0 to 5.0 % 0.0 %
C33 Input Terminal [AI1] Filter 0.00 to 5.00 s 0.05 s
C32
Input Terminal [AI1] Gain (Com-
mand)
0.00 to 400.00 % 100.00 %
C34
Input Terminal [AI1] Gain (Analog In-
put)
0.00 to 100.00 % 100.00 %
Bias adjustment on 1st frequency reference
F18
Input Terminal [AI1, AI2] Bias for 1st
Frequency Command
-100.00 to 100.00 % 0.00 %
C50
Input Terminal [AI1, AI2] Bias Analog
Input for 1st Frequency Command
0.00 to 100.00 % 0.00 %
Bias adjustment on 2nd frequency reference
C55 Input Terminal [AI1] Bias (Command) -200.00 to 200.00 % 0.00 %
C56
Input Terminal [AI1] Bias (Analog In-
put)
0.00 to 100.00 % 0.00 %
Input terminal [AI2] (AII) settings
7 Other Functions
7-38
M1 Series Standard Type User's Manual (I669)
