7-8-23
Inverter Output Limiting (IOL, IOL2)
This signal is output when the inverter is performing one of the limitation operations described below.
(Minimum output signal width 100 ms) The signal is output when the limitation operation in “22: IOL2
(Inverter output limiting with delay)” continues for 20 ms or longer
.
T
orque limit operation
Torque Limit 1/2/3/4 (F40/F41/E16/E17)
Current limitation operation by software
Overload Protect Function Selection (F43/E146), Overload Protect Level (F44/E147)
Current limitation operation by hardware
Instantaneous Overcurrent Limiting Function Selection (H12)
Anti-regenerative Control (H69)
Anti-regenerative Control Function Selection (H69)
Overload Stop Mode (J65)
Overload Stop Mode Selection (J65)
Parameter No. Function name Data Default data Unit
E20, E21, E27
Output Terminal [DO1]
Function Selection,
Output Terminal [DO2]
Function Selection,
Output Terminal [ROA,
ROB] Function Selec-
tion
5: IOL (Inverter output limiting)
22: IOL2 (Inverter output limiting with
delay)
- -
Related function
Output T
erminal [DO1] ON Delay Time (H309)
Output Terminal [DO2] ON Delay Time (H31
1)
Output Terminal [ROA, ROB] ON Delay Time (H313)
Output Terminal[DO1] OFF Delay Time (H310)
Output Terminal[DO2] OFF Delay Time (H312)
Output Terminal [ROA, ROB] OFF Delay Time (H314)
The OFF delay becomes the time obtained by adding 0.1 s to Output Terminal [DO1] OFF Delay Time
(H310), Output Terminal [DO2] OFF Delay Time (H312) and Output T
erminal [ROA, ROB] OFF Delay
Time (H314).
When the IOL signal or the ILO2 signal is ON, the output frequency of the inverter is automatically
controlled by the limitation processes described above, and thus, the set frequency may not be ach-
ieved.
7-8-24
Low-To-Moderate Voltage Detection (U-EDC)
This signal turns ON when the Main Circuit DC Voltage becomes equal to or below Main Circuit DC
Voltage low-voltage detection level (E76), and turns OFF when it becomes above the Main Circuit DC
Voltage low-voltage detection level (E76).
Parameter No. Function name Data Default data Unit
E76
Main Circuit DC Volt-
age Low-voltage De-
tection Level
200 to 400 V (200 V series)
400 to 800 V (400 V series)
235 V
7 Other Functions
7-106
M1 Series Standard Type User's Manual (I669)
