Parameter
No.
Function name Data
Default
data
Unit
J02
PID Control PID Command Se-
lection
0:
or keys on Operator
1: PID process command 1 (Analog
input terminals AI1, AI2(AII),
AI2(AIV))
3: Terminal command UP / DWN con-
trol
4: Communication
0 -
J03
PID Control P Proportional Gain 0.000 to 30.000 0.1 time
J04 PID Control I Integral Time 0.0 to 3600.0 0 s
J05 PID Control D Differential Time 0.00 to 600.00 0 s
J06 PID Control Feedback Filter 0.0 to 900.0 0.5 s
J10
PID Control Anti-reset Windup
Width
0 to 200 200 %
J11
PID Control Select Warning
Output Selection
0: Warning from absolute value
1: W
arning from absolute value with
hold
2: Warning from absolute value with
latch
3: W
arning from absolute value with
hold and latch
4: Warning from PID error
5: Warning from PID error with hold
6: Warning from PID error with latch
7: Warning from PID error with hold
and latch
0 -
J12
PID Control Upper Limit of
Warning (AH)
-100 to 100 100 %
J13
PID Control Lower Limit of
Warning (AL)
-100 to 100 0 %
J15
PID Control Sleep Frequency
for Process Control
0.0: Disable
1.0 to 590.0
0
Hz
J16
PID Control Sleep Timer for
Process Control
0 to 60 30 s
J17
PID Control Restart Frequency
after Stopping for Process Con-
trol
0.0 to 590.0 0 Hz
J18
PID Control PID Output Upper
Limit
-150 to 150
999: Depends on setting of F15
999 %
J19
PID Control PID Output Lower
Limit
-150 to 150
999: Depends on setting of F16
999 %
J23
PID Control Restart Feedback
Deviation after Stopping for
Process Control
0.0 to 100.0 0 %
J24
PID Control Restart Delay Time
after Stopping for Process Con-
trol
0 to 3600 0 s
J57
PID Control Operator PID Ref-
erence Position for Dancer
-100 to 0 to 100 0 %
7 Other Functions
7-124
M1 Series Standard Type User's Manual (I669)
