Parameter No. Function name Data Default data Unit
E01 to E05, E98,
E99
Input Terminal [DI1] to [DI7]
Function Selection
15: CS (Commercial switch)
16: SW60 (Commercial switch
(60 Hz))
- -
H13
Power Interruption Restart
W
ait Time
0.1 to 100.0 0.5
s
Switching between Inverter Operation and Commercial Power Sup-
ply Operation
• Follow the sequence diagram given below to switch among the terminals MC1 to MC3, FW and CS,
and switch from inverter operation to commercial power supply operation. When the CS terminal
turns ON, the inverter shuts off its output and the motor falls in a free-run state.
• When the commercial switching signal “CS” or “SW60” is turned OFF, the operation switches to in-
verter operation from commercial power supply operation, and following the elapse of the Power In-
terruption Restart W
ait Time (H13), the 50 Hz output starts when the signal during commercial 50
Hz selection turns OFF, and the 60 Hz output starts when the signal during commercial 60 Hz selec-
tion turns OFF. (Start of pull-in operation)
• If the output frequency is deviating from the motor rotation speed, perform adjustment of the output
frequency during the pull-in operation based on the fall rate of restart after momentary power failure
(H14).
7 Other Functions
7-142
M1 Series Standard Type User's Manual (I669)
