Parameter
No.
MODBUS ad-
dress (MSB)
MODBUS ad-
dress (LSB)
Parameter name
Communica-
tion data for-
mat (during
single-word
access)
Communica-
tion data for-
mat (during
double-word
access)
E01 30C1h -
Input Terminal [DI1] Function
Selection
1 -
E02 30C2h -
Input Terminal [DI2] Function
Selection
1 -
E03 30C3h -
Input Terminal [DI3] Function
Selection
1 -
E04 30C4h -
Input Terminal [DI4] Function
Selection
1 -
E05 30C5h -
Input Terminal [DI5] Function
Selection
1 -
E10 2102h 2103h 2nd Acceleration Time 1 12 6
E11 2104h 2105h 2nd Deceleration Time 1 12 6
E12 1273h 1274h 1st Acceleration Time 2 12 6
E13 1275h 1276h 1st Deceleration Time 2 12 6
E14 226Eh 226Fh 2nd Acceleration Time 2 12 6
E15 2270h 2271h 2nd Deceleration Time 2 12 6
E16 132Ch - Torque Limit 3 1 -
E17 132Dh - Torque Limit 4 1 -
E20 30DAh -
Output Terminal [DO1] Func-
tion Selection
1 -
E21 30DBh -
Output Terminal [DO2] Func-
tion Selection
1 -
E27 30E1h -
Output Terminal [ROA, ROB]
Function Selection
1 -
E29 30E3h - Frequency Arrival 2 ON Timer 5 -
E30 30E4h -
Frequency Arrival Detection
Width (F
AR1/F
AR2/F
AR3/
FDT3/FDT4)
3 -
E31 30E5h 30E6h
Frequency Detection Level1
(FDT1/FDT3)
3 3
E32 30E7h 30E8h
Frequency Detection Hystere-
sis Width (FDT1/ FDT2)
3 3
E34 30EAh -
Overload early warning 2 Lev-
el (OL2)
19 -
E35 30EBh -
Overload early warning 2 De-
tection T
imer (OL2)
5 -
E36 30ECh
30EDh
Frequency Detection Level 2
(FDT2/FDT4)
3 3
E37 30EEh -
1st Overload Early Warning
Detection Level
19 -
E38 30EFh -
1st Overload Early Warning
Detection T
imer / Low Current
detection level (OL, LOC)
5 -
8 Communications Functions
8-49
M1 Series Standard Type User's Manual (I669)
8-9 Modbus Communication Data Lists
8
8-9-2 Register List
