Parameter

No.

MODBUS ad-

dress (MSB)

MODBUS ad-

dress (LSB)

Parameter name

Communica-

tion data for-

mat (during

single-word

access)

Communica-

tion data for-

mat (during

double-word

access)

E177 31DCh - Non-linear V/f Voltage 6 1 -

E178 31DDh - Non-linear V/f Frequency 7 3 -

E179 31DEh - Non-linear V/f Voltage 7 1 -

E181 31E0h -

Acceleration Wait Time on

Brake Control

7 -

E184 31E3h -

Low Current Detection Condi-

tion Selection (LOC)

1 -

E185 31E4h -

Overload Warning Detection

Condition Selection (OL1,

OL2)

1 -

E196 31F3h -

Overtorque/Undertorque De-

tection Level Reverse Power

Running

1 -

E197 31F4h -

Overtorque/Undertorque De-

tection Level Forward Regen-

eration

1 -

E198 31F5h -

Overtorque/Undertorque De-

tection Condition Selection

1 -

E199 31F6h -

0Hz Detection Output Detec-

tion Level (ZS)

5 -

C01 3241h 3242h Jump Frequency 1 3 3

C02 3243h 3244h Jump Frequency 2 3 3

C03 3245h 3246h Jump Frequency 3 3 3

C04 3247h - Jump Frequency Skip Width 3 -

C05 1217h 1218h

Multi-step Frequency Refer-

ence 1

22 5

C06 1219h 121Ah

Multi-step Frequency Refer-

ence 2

22 5

C07 121Bh 121Ch

Multi-step Frequency Refer-

ence 3

22 5

C08 121Dh 121Eh

Multi-step Frequency Refer-

ence 4

22 5

C09 121Fh 1220h

Multi-step Frequency Refer-

ence 5

22 5

C10 1221h 1222h

Multi-step Frequency Refer-

ence 6

22 5

C11 1223h 1224h

Multi-step Frequency Refer-

ence 7

22 5

C12 1225h 1226h

Multi-step Frequency Refer-

ence 8

22 5

C13 1227h 1228h

Multi-step Frequency Refer-

ence 9

22 5

C14 1229h 122Ah

Multi-step Frequency Refer-

ence 10

22 5

C15 122Bh 122Ch

Multi-step Frequency Refer-

ence 1

22 5

8 Communications Functions

8-53

M1 Series Standard Type User's Manual (I669)

8-9 Modbus Communication Data Lists

8-9-2 Register List
