Parameter

No.

MODBUS ad-

dress (MSB)

MODBUS ad-

dress (LSB)

Parameter name

Communica-

tion data for-

mat (during

single-word

access)

Communica-

tion data for-

mat (during

double-word

access)

H198 34E2h -

User Password 1 Setting/Veri-

fication

1 -

H199 34E3h - User Password 1 Setting 1 -

H303 3604h -

Co-Inverter Communication

Function Selection

1 -

H304 3605h -

Co-inverter Communication

Starting Station Number (Ad-

ministrator)

1 -

H305 3606h -

Co-inverter Communication

Ending Station Number (Ad-

ministrator)

1 -

H306 3607h -

Co-inverter Communication

Start Selection (Administrator)

1 -

H309 360Ah -

Output Terminal [DO1] ON

Delay T

ime

3 -

H310

360Bh -

Output T

erminal[DO1] OFF

Delay Time

3 -

H311

360Ch -

Output Terminal [DO2] ON

Delay Time

3 -

H312 360Dh -

Output T

erminal[DO2] OFF

Delay Time

3 -

H313 360Eh -

Output T

erminal [ROA, ROB]

ON Delay Time

3 -

H314 360Fh -

Output T

erminal [ROA, ROB]

OFF Delay Time

3 -

H315 3610h -

Logical Expression 1 Opera-

tion Target 1

1 -

H316 361

1h -

Logical Expression 1 Opera-

tion Target 2

1 -

H317 3612h -

Logical Expression 1 Logical

Operator

1 -

H318

3613h -

Logical Expression 2 Opera-

tion Target 1

1 -

H319 3614h -

Logical Expression 2 Opera-

tion Target 2

1 -

H320 3615h -

Logical Expression 2 Logical

Operator

1 -

H321

3616h -

Logical Expression 3 Opera-

tion Target 1

1 -

H322 3617h -

Logical Expression 3 Opera-

tion Target 2

1 -

H323 3618h -

Logical Expression 3 Logical

Operator

1 -

H324

3619h -

Input Terminal [DI1] Response

Time

1 -

H325 361Ah -

Input T

erminal [DI2] Response

Time

1 -

8 Communications Functions

8-61

M1 Series Standard Type User's Manual (I669)

8-9 Modbus Communication Data Lists

8-9-2 Register List
