Parameter
No.
MODBUS ad-
dress (MSB)
MODBUS ad-
dress (LSB)
Parameter name
Communica-
tion data for-
mat (during
single-word
access)
Communica-
tion data for-
mat (during
double-word
access)
A48 3870h - Speed Control 2 Output Filter 7 -
A49 3871h -
Speed Control 2 Notch Filter
Resonance Frequency
1 -
A50 3872h -
Speed Control 2 Notch Filter
Attenuation Level
1 -
A51 3873h -
2nd Cumulative Motor Run
T
ime
74 -
A52 3874h - 2nd Startup Counter for Motor 1 -
A53 3875h -
2nd Motor 2 %X Correction
Factor 1
1 -
A55 3877h -
Torque Current for 2nd Vector
Control
19 -
A56 3878h -
Induced Voltage Factor for
2nd V
ector Control
1 -
A57 3879h -
Reserved 7 -
A60 387Ch -
2nd Speed Conversion Coeffi-
cient
5 -
A61 387Dh -
2nd Display Coefficient for
T
ransport time / Auxiliary Dis-
play Coef
ficient for Speed
Monitor
45 -
A62
387Eh -
2nd Starting Frequency Hold-
ing Time
5 -
A63 387Fh -
2nd Stop Frequency 3 -
A64 3880h -
2nd Stop Frequency Detec-
tion Method Selection
1 -
A65 3881h -
2nd Stop Frequency Holding
T
ime
5 -
b43 392Bh -
Speed Control 3 Speed Com-
mand Filter
7 -
b44
392Ch -
Speed Control 3 Speed De-
tection Filter
7 -
b45 392Dh -
Speed Control 3 P Proportion-
al Gain
3 -
b46 392Eh -
Speed Control 3 I Integral
T
ime
7 -
b47 392Fh -
Speed Control 3 FF Gain 5 -
b48 3930h - Speed Control 3 Output Filter 7 -
b49 3931h -
Speed Control 3 Notch Filter
Resonance Frequency
1 -
b50 3932h -
Speed Control 3 Notch Filter
Attenuation Level
1 -
r43 39EBh -
Speed Control 4 Speed Com-
mand Filter
7 -
r44 39ECh -
Speed Control 4 Speed De-
tection Filter
7 -
8 Communications Functions
8-67
M1 Series Standard Type User's Manual (I669)
8-9 Modbus Communication Data Lists
8
8-9-2 Register List
