Parameter No. Function name Data
Default
data
Unit
S06 Operation command
Bit15: RST
Bit14: DI7
Bit13: DI6
Bit12: ---
Bit11: ---
Bit10: ---
Bit9: ---
Bit8: ---
Bit7: ---
Bit6: DI5
Bit5: DI4
Bit4: DI3
Bit3: DI2
Bit2: DI1
Bit1: REV
Bit0: FWD
0 -
S07
Communication Data T
ermi-
nal [DO]
Bit15: ---
Bit14: ---
Bit13: ---
Bit12: ---
Bit11: ---
Bit10: ---
Bit9: ---
Bit8: RO
Bit7: ---
Bit6: ---
Bit5: ---
Bit4: ---
Bit3: ---
Bit2: ---
Bit1: DO2
Bit0: DO1
0 -
S12
Communication Data T
ermi-
nal [AO]
-32,768 to 32,767 0 %
