Omron M1 Series User Manual

Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Inverter output (U, V, W)
HHD mode HND mode
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
- 3G3M1-A2002 0.4 - - - - 2.0 2.0 2.0 2.0
3G3M1-A2004 - 2.0 2.0 2.0 3.0 - - - -
- 3G3M1-A2004 0.75 - - - - 2.0 2.0 2.0 3.5
3G3M1-A2007 - 2.0 2.0 2.0 5.0 - - - -
- 3G3M1-A2007 1.1 - - - - 2.0 2.0 2.0 6.0
3G3M1-A2015 - 1.5 2.0 2.0 2.0 8.0 - - - -
- 3G3M1-A2015 2.2 - - - - 2.0 2.0 2.0 9.6
3G3M1-A2022 - 2.0 2.0 2.0 11.0 - - - -
- 3G3M1-A2022 3 - - - - 2.0 2.0 2.0 12.0
3G3M1-A2037 - 3.7 3.5 2.0 2.0 17.5 - - - -
- 3G3M1-A2037 5.5 - - - - 3.5 2.0 2.0 19.6
3G3M1-A2055 - 5.5 3.5 2.0 25.0 - - - -
3G3M1-A2075 3G3M1-A2055 7.5 8.0 3.5 3.5 33.0 8.0 3.5 2.0 30.0
3G3M1-A2110 3G3M1-A2075 11 14.0 8.0 5.5 47.0 14.0 5.5 3.5 40.0
3G3M1-A2150 3G3M1-A2110 15 22.0 14.0 8.0 60.0 22.0 14.0 5.5 56.0
3G3M1-A2220 3G3M1-A2150 18.5
38.0
*1
14.0 14.0 76.0
38.0
*1
14.0 8.0 69.0
- 3G3M1-A2220 22 - - - -
38.0
*1
22.0 14.0 88.0
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size
[mm2]
DC reactor connection (P1,
P(+))
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C
3G3M1-A2001 - 0.1 2.0 2.0 2.0 0.7
3G3M1-A2002 3G3M1-A2001 0.2 2.0 2.0 2.0 1.1
- 3G3M1-A2002 0.4 2.0 2.0 2.0 2.0
3G3M1-A2004 - 2.0 2.0 2.0 2.0
- 3G3M1-A2004 0.75 2.0 2.0 2.0 3.7
3G3M1-A2007 - 2.0 2.0 2.0 3.7
- 3G3M1-A2007 1.1 2.0 2.0 2.0 5.3
3G3M1-A2015 - 1.5 2.0 2.0 2.0 7.0
- 3G3M1-A2015 2.2 2.0 2.0 2.0 10.2
3G3M1-A2022 - 2.0 2.0 2.0 10.2
- 3G3M1-A2022 3 2.0 2.0 2.0 14.3
3G3M1-A2037 - 3.7 3.5 2.0 2.0 17.1
- 3G3M1-A2037 5.5 5.5 3.5 2.0 24.4
3G3M1-A2055 - 5.5 3.5 2.0 25.8
2 Design
2-20
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
