Omron M1 Series User Manual

Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire
size [mm2]
Inverter ground (G)
HHD mode HND mode
Allowable tempera-
ture (Note 1)
60°C 75°C 90°C
3G3M1-A2001 - 0.1 2.0 2.0 2.0
3G3M1-A2002 3G3M1-A2001 0.2 2.0 2.0 2.0
- 3G3M1-A2002 0.4 2.0 2.0 2.0
3G3M1-A2004 - 2.0 2.0 2.0
- 3G3M1-A2004 0.75 2.0 2.0 2.0
3G3M1-A2007 - 2.0 2.0 2.0
- 3G3M1-A2007 1.1 2.0 2.0 2.0
3G3M1-A2015 - 1.5 2.0 2.0 2.0
- 3G3M1-A2015 2.2 2.0 2.0 2.0
3G3M1-A2022 - 2.0 2.0 2.0
- 3G3M1-A2022 3 2.0 2.0 2.0
3G3M1-A2037 - 3.7 2.0 2.0 2.0
- 3G3M1-A2037 5.5 3.5 3.5 3.5
3G3M1-A2055 - 3.5 3.5 3.5
3G3M1-A2075 3G3M1-A2055 7.5 5.5 5.5 5.5
3G3M1-A2110 3G3M1-A2075 11 5.5 5.5 5.5
3G3M1-A2150 3G3M1-A2110 15 5.5 5.5 5.5
3G3M1-A2220 3G3M1-A2150 18.5 8.0 8.0 8.0
- 3G3M1-A2220 22 8.0 8.0 8.0

Three-phase 400-V class (Panel internal temperature 50°C or less)
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Main power supply input (L1/R, L2/S, L3/T)
When DC reactor (DCR) is
used
Without DC reactor (DCR)
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-A4004 - 0.4 2.0 2.0 2.0 0.9 2.0 2.0 2.0 1.7
- 3G3M1-A4004 0.75 2.0 2.0 2.0 1.5 2.0 2.0 2.0 2.7
3G3M1-A4007 - 2.0 2.0 2.0 1.6 2.0 2.0 2.0 3.1
- 3G3M1-A4007 1.1 2.0 2.0 2.0 2.1 2.0 2.0 2.0 3.9
3G3M1-A4015 - 1.5 2.0 2.0 2.0 3.0 2.0 2.0 2.0 5.9
- 3G3M1-A4015 2.2 2.0 2.0 2.0 4.2 2.0 2.0 2.0 7.3
3G3M1-A4022 - 2.0 2.0 2.0 4.4 2.0 2.0 2.0 8.2
- 3G3M1-A4022 3 2.0 2.0 2.0 5.8 2.0 2.0 2.0 11.3
3G3M1-A4030 -
- 3G3M1-A4030 3.7 2.0 2.0 2.0 7.3 2.0 2.0 2.0 13.0
3G3M1-A4040 -
2 Design
2-22
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
