Omron M1 Series User Manual

Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Main power supply input (L1/R, L2/S, L3/T)
When DC reactor (DCR) is
used
Without DC reactor (DCR)
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
- 3G3M1-A4040 5.5 2.0 2.0 2.0 10.1 3.5 2.0 2.0 16.8
3G3M1-A4055 - 2.0 2.0 2.0 10.6 3.5 2.0 2.0 17.3
3G3M1-A4075 3G3M1-A4055 7.5 2.0 2.0 2.0 14.4 5.5 2.0 2.0 23.2
3G3M1-A4110 3G3M1-A4075 11 5.5 2.0 2.0 21.1 8.0 3.5 3.5 33.0
3G3M1-A4150 3G3M1-A4110 15 8.0 3.5 2.0 28.8 14.0 5.5 5.5 43.8
3G3M1-A4185 3G3M1-A4150 18.5 14.0 5.5 3.5 35.5 22.0 8.0 5.5 52.3
3G3M1-A4220 3G3M1-A4185 22 14.0 5.5 5.5 42.2 22.0 14.0 8.0 60.6
- 3G3M1-A4220 30 22.0 14.0 8.0 57.0
38.0
*1
14.0 14.0 77.9
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Inverter output (U, V, W)
HHD mode HND mode
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-A4004 - 0.4 2.0 2.0 2.0 1.8 - - - -
- 3G3M1-A4004 0.75 - - - - 2.0 2.0 2.0 2.1
3G3M1-A4007 - 2.0 2.0 2.0 3.4 - - - -
- 3G3M1-A4007 1.1 - - - - 2.0 2.0 2.0 4.1
3G3M1-A4015 - 1.5 2.0 2.0 2.0 4.8 - - - -
- 3G3M1-A4015 2.2 - - - - 2.0 2.0 2.0 5.5
3G3M1-A4022 - 2.0 2.0 2.0 5.5 - - - -
- 3G3M1-A4022 3 - - - - 2.0 2.0 2.0 6.9
3G3M1-A4030 -
- 3G3M1-A4030 3.7 2.0 2.0 2.0 9.2 - - - -
3G3M1-A4040 -
- 3G3M1-A4040 5.5 - - - - 2.0 2.0 2.0 11.1
3G3M1-A4055 - 2.0 2.0 2.0 14.8 - - - -
3G3M1-A4075 3G3M1-A4055 7.5 3.5 2.0 2.0 18.0 3.5 2.0 2.0 17.5
3G3M1-A4110 3G3M1-A4075 11 5.5 2.0 2.0 24.0 5.5 2.0 2.0 23.0
3G3M1-A4150 3G3M1-A4110 15 8.0 3.5 2.0 31.0 8.0 5.5 3.5 31.0
3G3M1-A4185 3G3M1-A4150 18.5 14.0 5.5 3.5 39.0 14.0 5.5 3.5 38.0
3G3M1-A4220 3G3M1-A4185 22 14.0 8.0 5.5 45.0 14.0 8.0 5.5 45.0
- 3G3M1-A4220 30 - - - - 22.0 14.0 8.0 60.0
2 Design
2-23
M1 Series Standard Type User's Manual (I669)
2-3 Wiring
2
2-3-4 Wiring for Main Circuit Terminals

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
