Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size
[mm2]
DC reactor connection (P1,
P(+))
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C
3G3M1-A4004 - 0.4 2.0 2.0 2.0 1.0
- 3G3M1-A4004 0.75 2.0 2.0 2.0 1.8
3G3M1-A4007 - 2.0 2.0 2.0 2.0
- 3G3M1-A4007 1.1 2.0 2.0 2.0 2.6
3G3M1-A4015 - 1.5 2.0 2.0 2.0 3.7
- 3G3M1-A4015 2.2 2.0 2.0 2.0 5.1
3G3M1-A4022 - 2.0 2.0 2.0 5.4
- 3G3M1-A4022 3 2.0 2.0 2.0 7.1
3G3M1-A4030 -
- 3G3M1-A4030 3.7 2.0 2.0 2.0 8.9
3G3M1-A4040 -
- 3G3M1-A4040 5.5 2.0 2.0 2.0 12.4
3G3M1-A4055 - 2.0 2.0 2.0 13.0
3G3M1-A4075 3G3M1-A4055 7.5 3.5 2.0 2.0 17.6
3G3M1-A4110 3G3M1-A4075 11 5.5 3.5 2.0 25.8
3G3M1-A4150 3G3M1-A4110 15 14.0 5.5 3.5 35.3
3G3M1-A4185 3G3M1-A4150 18.5 14.0 5.5 5.5 43.5
3G3M1-A4220 3G3M1-A4185 22 22.0 8.0 5.5 51.7
- 3G3M1-A4220 30
38.0
*1
14.0 8.0 69.8
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Brake resistance connection (P(+), DB)
HHD mode HND mode
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-A4004 - 0.4 2.0 2.0 2.0 0.4 - - - -
- 3G3M1-A4004 0.75 - - - - 2.0 2.0 2.0 0.4
3G3M1-A4007 - 2.0 2.0 2.0 0.5 - - - -
- 3G3M1-A4007 1.1 - - - - 2.0 2.0 2.0 0.6
3G3M1-A4015 - 1.5 2.0 2.0 2.0 0.7 - - - -
- 3G3M1-A4015 2.2 - - - - 2.0 2.0 2.0 0.8
3G3M1-A4022 - 2.0 2.0 2.0 0.9 - - - -
- 3G3M1-A4022 3 - - - - 2.0 2.0 2.0 0.9
3G3M1-A4030 -
- 3G3M1-A4030 3.7 2.0 2.0 2.0 1.2 - - - -
3G3M1-A4040 -
2 Design
2-24
M1 Series Standard Type User's Manual (I669)
To Next Page
