Omron M1 Series User Manual

Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Brake resistance connection (P(+), DB)
HHD mode HND mode
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
- 3G3M1-A4040 5.5 - - - - 2.0 2.0 2.0 1.3
3G3M1-A4055 - 2.0 2.0 2.0 1.9 - - - -
3G3M1-A4075 3G3M1-A4055 7.5 2.0 2.0 2.0 2.5 2.0 2.0 2.0 1.9
3G3M1-A4110 3G3M1-A4075 11 2.0 2.0 2.0 3.8 2.0 2.0 2.0 2.7
3G3M1-A4150 3G3M1-A4110 15 2.0 2.0 2.0 4.7 2.0 2.0 2.0 3.8
3G3M1-A4185 3G3M1-A4150 18.5 2.0 2.0 2.0 6.5 2.0 2.0 2.0 4.5
3G3M1-A4220 3G3M1-A4185 22 2.0 2.0 2.0 7.1 2.0 2.0 2.0 6.2
- 3G3M1-A4220 30 - - - - 2.0 2.0 2.0 7.2
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire
size [mm2]
Inverter ground (G)
HHD mode HND mode
Allowable tempera-
ture (Note 1)
60°C 75°C 90°C
3G3M1-A4004 - 0.4 2.0 2.0 2.0
- 3G3M1-A4004 0.75 2.0 2.0 2.0
3G3M1-A4007 - 2.0 2.0 2.0
- 3G3M1-A4007 1.1 2.0 2.0 2.0
3G3M1-A4015 - 1.5 2.0 2.0 2.0
- 3G3M1-A4015 2.2 2.0 2.0 2.0
3G3M1-A4022 - 2.0 2.0 2.0
- 3G3M1-A4022 3 2.0 2.0 2.0
3G3M1-A4030 -
- 3G3M1-A4030 3.7 2.0 2.0 2.0
3G3M1-A4040 -
- 3G3M1-A4040 5.5 2.0 2.0 2.0
3G3M1-A4055 - 2.0 2.0 2.0
3G3M1-A4075 3G3M1-A4055 7.5 2.0 2.0 2.0
3G3M1-A4110 3G3M1-A4075 11 3.5 3.5 3.5
3G3M1-A4150 3G3M1-A4110 15 5.5 5.5 5.5
3G3M1-A4185 3G3M1-A4150 18.5 5.5 5.5 5.5
3G3M1-A4220 3G3M1-A4185 22 5.5 5.5 5.5
- 3G3M1-A4220 30 8.0 8.0 8.0
2 Design
2-25
M1 Series Standard Type User's Manual (I669)
2-3 Wiring
2
2-3-4 Wiring for Main Circuit Terminals

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
