Omron M1 Series User Manual


Single-phase 200-V class (Panel internal temperature 50°C or less)
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Main power supply input (L1/R, L2/S, L3/T)
When DC reactor (DCR) is
used
Without DC reactor (DCR)
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-AB001 - 0.1 2.0 2.0 2.0 1.1 2.0 2.0 2.0 1.8
- 3G3M1-AB001 0.2 2.0 2.0 2.0 2.7 2.0 2.0 2.0 2.0
3G3M1-AB002 - 2.0 2.0 2.0 2.0 2.0 2.0 2.0 3.3
- 3G3M1-AB002 0.4 2.0 2.0 2.0 3.7 2.0 2.0 2.0 3.6
3G3M1-AB004 - 2.0 2.0 2.0 3.5 2.0 2.0 2.0 5.4
- 3G3M1-AB004 0.55 2.0 2.0 2.0 4.6 2.0 2.0 2.0 7.3
3G3M1-AB007 - 0.75 2.0 2.0 2.0 6.4 2.0 2.0 2.0 9.7
- 3G3M1-AB007 1.1 2.0 2.0 2.0 9.4 2.0 2.0 2.0 13.8
3G3M1-AB015 - 1.5 2.0 2.0 2.0 11.6 3.5 2.0 2.0 16.4
- 3G3M1-AB015 2.2 3.5 2.0 2.0 17.9 3.5 2.0 2.0 20.2
3G3M1-AB022 - 3.5 2.0 2.0 17.5 5.5 2.0 2.0 22.0
- 3G3M1-AB022 3 5.5 3.5 2.0 25.0 5.5 2.0 2.0 24.0
3G3M1-AB037 - 3.7 8.0 3.5 3.5 31.8 14.0 8.0 5.5 45.4
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Inverter output (U, V, W)
HHD mode HND mode
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-AB001 - 0.1 2.0 2.0 2.0 1.0 - - - -
- 3G3M1-AB001 0.2 - - - - 2.0 2.0 2.0 1.2
3G3M1-AB002 - 2.0 2.0 2.0 1.6 - - - -
- 3G3M1-AB002 0.4 - - - - 2.0 2.0 2.0 1.9
3G3M1-AB004 - 2.0 2.0 2.0 3.0 - - - -
- 3G3M1-AB004 0.55 - - - - 2.0 2.0 2.0 3.5
3G3M1-AB007 - 0.75 2.0 2.0 2.0 5.0 - - - -
- 3G3M1-AB007 1.1 - - - - 2.0 2.0 2.0 6.0
3G3M1-AB015 - 1.5 2.0 2.0 2.0 8.0 - - - -
- 3G3M1-AB015 2.2 - - - - 2.0 2.0 2.0 9.6
3G3M1-AB022 - 2.0 2.0 2.0 11.0 - - - -
- 3G3M1-AB022 3 - - - - 2.0 2.0 2.0 12.0
3G3M1-AB037 - 3.7 3.5 2.0 2.0 17.5 - - - -
2 Design
2-26
M1 Series Standard Type User's Manual (I669)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
