Displaying User Messages on an NJ-series-compatible NS-series PT When a Major Fault
Level Controller Error Occurs:
When a major fault level Controller error occurs, the user program execution stops. The NJ-
series Controllers can display user messages on an NJ-series-compatible NS-series PT when a
major fault level Controller error occurs. You can set the display messages under the list of user-
defined events in the Event Setting Table on the Sysmac Studio.
Item Description Values
Event Code You can specify a number to identify the
event according to the event level.
User-defined error: 1 to 40,000
User-defined information: 40,001 to
60,000
Event Name You can include a title for the event. 128 characters max.
Event Level You can specify the level of the event.
The level is indicated with a number.
The lower the number is, the higher the
level is.
User-defined error: User fault levels: 1 to
8
User-defined information: User informa-
tion
Group You can specify a group name to repre-
sent the location or type of the event.
You can use user-defined groupings for
the events.
32 characters max.
There are no restrictions on the charac-
ters that can be used. Case sensitive.
Reserved words: None
Details You can include a message that
describes the event. The user can enter
any text string. The message is used
when the event is displayed on the Sys-
mac Studio or an HMI.
1,024 characters max.
There are no restrictions on the charac-
ters that can be used. Case sensitive.
Reserved words: None
Error details that are
displayed on the HMI
when a major fault level
Controller error occurs
Refer to the additional information that is
given below on displaying user mes-
sages on an NJ-series-compatible NS-
series PT when a major fault level Con-
troller error occurs for more details.
128 characters max.
There are no restrictions on the charac-
ters that can be used.
Case sensitive. Reserved words: None
Comment The comment is attached for each set of
table entries.
