8-6 Event Logs
8
8-6-4 User-defined Events (User-defined Errors and Information)
To create a user-defined error or user-defined information, register the user-defined error or user-
defined information in the Event Setting Table in the Sysmac Studio in advance. The user events that
you set here can be displayed on the Sysmac Studio or NJ-series-compatible NS-series PT with the
same information. You can register up to 5,120 events in the Event Setting Table.
Event Setting Table Tab Page
The following items are set in the Event Setting Table.
Setting the Event Setting Table
10001
User fault Level3
Var1
Var2
SetAlarm
EN
Code
Info1
Info2
ENO
Description
Failure
Detection condition
Programming Example
Perform safety checks and handle the problem
according to the cause code.
Correction
Failure X occurred.
Details
Control A (001)
Failure X
Details
Group
Level Event name
Event code
Event Setting Table
Normal end
OutVal
UINT#102
