12 Troubleshooting
12-50
NJ-series CPU Unit Software User’s Manual (W501)
Errors Related to FINS Communications
Event name CPU Bus Unit Setup Area Error Event code 14010000 hex
Meaning An error was detected in the memory check of the Setup Area for CPU Bus Units.
Source PLC Function Module Source details None Detection
timing
At power ON, at
Controller reset,
or when writing
CPU Bus Unit
Setup Area
Error attributes Level Minor fault Recovery Error reset or
cycling power
supply
Log category System
Effects User program Continues. Operation The CPU Bus Unit may stop.
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The power supply to the Controller
was interrupted or communications
with the Sysmac Studio were discon-
nected while downloading the CPU
Bus Unit Settings.
Clear all memory or download the
CPU Bus Unit Settings. If this error
persists, replace the CPU Unit.
Do not interrupt the power supply to
the Controller or disconnect commu-
nications with the Sysmac Studio
while downloading the CPU Bus Unit
Settings.
Attached
information
None
Precautions/
Remarks
None
Event name IP Address Table Setting Error Event code 3410 0000 hex
Meaning The IP address table settings are incorrect.
Source PLC Function Module Source details None Detection
timing
At power ON,
Controller reset,
or restart of built-
in Ethernet port
Error attributes Level Minor fault Recovery Error reset Log category System
Effects User program Continues. Operation FINS/UDP communications will not operate.
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The IP address conversion method is
set to the combined method or the IP
address table method, but the IP
address table settings are incorrect.
Correct the IP address table settings. Set the IP address table correctly.
Attached
information
None
Precautions/
Remarks
None
