12-51
12 Troubleshooting
NJ-series CPU Unit Software User’s Manual (W501)
12-2 Troubleshooting
12
12-2-4 Error Descriptions
Event name FINS/TCP Connection Table Setting Error Event code 34130000 hex
Meaning The FINS/TCP connection table is incorrect.
Source PLC Function Module Source details None Detection
timing
At power ON,
Controller reset,
or restart of built-
in Ethernet port
Error attributes Level Minor fault Recovery Error reset Log category System
Effects User program Continues. Operation FINS/UDP communications will not operate.
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The power supply to the Controller
was interrupted or communications
with the Sysmac Studio were discon-
nected while downloading the
FINS/TCP connection table.
Download the FINS/TCP connection
table again.
Do not interrupt the power supply to
the Controller or disconnect commu-
nications with the Sysmac Studio
while downloading the FINS/TCP
connection table.
Attached
information
None
Precautions/
Remarks
None
Event name Unknown Destination Node Event code 34110000 hex
Meaning The send destination node is not known.
Source PLC Function Module Source details None Detection
timing
At FINS message
reception
Error attributes Level Observation Recovery --- Log category System
Effects User program Continues. Operation Not affected. Packets are discarded.
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
The send destination node was not
found when a FINS message was
sent.
Correct the setting of the send desti-
nation node for FINS/UDP communi-
cations. Or, check the source FINS
message and correct the destination
node address.
Set the send destination node for
FINS/UDP communications correctly.
Or, make sure that the destination
node address in the source FINS
message is correct.
Attached
information
None
Precautions/
Remarks
None
