Appendices
A-118
NJ-series CPU Unit Software User’s Manual (W501)
Use the Sysmac Studio’s variable and memory backup function to upload the present values of vari-
ables and memory. Refer to 9-7 Sysmac Studio Variable and Memory Backup Functions for details on
the Sysmac Studio variable and memory backup functions.
Use the following procedure.
1 Select Backup  Backup Variables and Memory from the Tools Menu on the Sysmac Stu-
dio.
2 Select the Present value of Retain attribute variable, DM, EM and Holding Memory used
for CJ -series Units, and Absolute encoder home offset value Check Boxes and click the
Execute Button.
The variable and memory data is uploaded to the computer.
Uploading the Present Values of Variables and Memory

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
