100

Chapter4

OS32C

User’s Manual

Installation

External Dimensional Drawings

 OS32C with Back Location Cable Entry /with EIP and Back Location Cable Entry　

(OS32C-BP/OS32C-BP-DM)

Fig. 4-18 OS32C with Back Cable Entry Dimensional Drawing

 OS32C with Side Location Cable Entry /with EIP and Side Location Cable Entry

(OS32C-SP1/OS32C-SP1-DM)

Fig. 4-19 OS32C with Side Cable Entry Dimensional Drawing

M5 x 0.8,

DEPTH 9.0 [0.35] MAX (x4)

M5 x 0.8,

DEPTH 9.0 [0.35]

MAX (x4)

18.2 [0.72]

39.0 [1.54]

25.0 [0.99]
