33
OS32C
User’s Manual
Chapter3
Basic Operation of Configuration Software
E
Getting Started
The configuration and installation of an OS32C is a simple process. Here are the basic steps needed to get
started. Refer to the appropriate section of Chapter 3 for more information on any of these steps.
• Install the configuration tool
• Connect the OS32C to the same network as the computer
• Start the configuration tool
• Discover scanners on the network
• Log on to the OS32C
- Select Access Level
- Enter password
• Create new configuration
- Safety-critical parameters (EDM, response time, operating mode, zone sets, minimum object resolution
etc.)
- Non-safety-critical parameters (auxiliary output, warning output, power consumption mode, etc)
- Zone configuration
• Send configuration to the OS32C
Installing Configuration Software
Installation of the configuration software for the OS32C requires the following:
• Pentium 4 class 1.5GHz CPU or equivalent
• Windows 2000, Windows XP, Windows Vista, or Windows 7
•512MB of RAM
• 10MB of available hard disk space
• Monitor with resolution of 1024 x 768 pixels or better.
Install the software based on the following steps:
1. Terminate all applications running.
2. Insert CD-ROM of the configuration software to your CD drive.
3. Double-click the CD-ROM icon in My Computer to run Setup.exe.
4. Follow instructions of the installer program.
5. A program icon appears where you specified during installation.
To install the configuration software on Windows 2000, Windows XP Professional, Windows Vista, or Windows 7, a user
account of supervisory access level (Administrators) is required.
