109
OS32C
User’s Manual
Chapter4
Installation
E
 Tightening Torque
Refer to table below for tightening torque:
Table 4-1
 Power Cable
Fig. 4-36 External dimensional drawing of power cable
 Ethernet Cable
Fig. 4-37 External dimensional drawing of ethernet cable
Bolt Diameter Tightening Torque
M3.5 1.4 N
•m
M5 3.4 N
•m
M6 3.6 N
•m
M8 3.6 N
•m
Model Number
3m
Length in m
* SIZES ARE AS BELOW
L *
(90)
(56)
(30)
NAME PLATE
Vinyl insulated round cable (diameter max. 10mm) Black
18-core (conductor section area 0.3 mm
2
,
insulator diameter max. 1.5 mm)
Standard length L (See *)
OS32C-CBL-03M
(Unit : mm)
10m
OS32C-CBL-10M
20m
OS32C-CBL-20M
30m
OS32C-CBL-30M
M12
TWIST TIE
L (CABLE LENGTH)
44.7 54.7
Model Number
2m
Length in m
OS32C-ECBL-02M
5m
OS32C-ECBL-05M
15m
OS32C-ECBL-15M
Vinyl insulated round cable (diameter max 6.5mm)
Light blue 4-core (conductor section area 0.34mm
2
, insulator
diameter max 1.57mm)
Standard length L (See *)
RJ45
* SIZES ARE AS BELOW
