Page #23 background image
3
OS32C
User’s Manual
Chapter1
Description of Use and Features
E
Features
Can detect intrusions within the safety zone with a radius of up to 3m (min. obj. resolution of 50mm or 70mm)
and two warning zones with a radius of 10m, covering a maximum scan angle of 270
°
.
When an object is detected within the safety zone, individual sector indicators immediately turn on (8 red
indicators), indicating the object’s position of intrusion.
Seventy sets of safety zone and warning zone combinations are available, supporting complicated changes
of working environments.
The configuration software allows easy to use monitoring zone configuration.
A safety relay can be directly monitored by the external device monitoring function.
The physical mounting position of the safety laser scanner can be monitored by the reference boundary
monitoring function.
Compact design allows for low-clearance installations.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Omron OS32C Series and is the answer not in the manual?

Omron OS32C Series Specifications

General IconGeneral
Response Time80 ms
TypeSafety Laser Scanner
Protection StructureIP65
Safety CategoryType 3
Power Supply24 VDC
InterfaceEthernet/IP, PROFINET
Operating Temperature-10°C to 50°C
OutputOSSD
CommunicationEthernet/IP
ConfigurationVia software
Warning ZoneConfigurable
