Table 7-1 Diagnostic Code References
Other fault 50 General fault - caused by internal
problem or extreme environmental
condition
Check environment for excessive
vibration, shock or electrical noise; check
that the window assembly is undamaged
and securely attached. Or consult
factory.
51 Mutual interference Check for mutual interference with
another scanner (see mounting
considerations on the user manual),
nearby retro reflectors (<1m) or strong
interfering light sources.
Mounting Considerations p.84
52 General fault - caused by internal
problem or extreme environmental
condition
Check the environment for electrical
noise sources or interfering light sources.
Or consult factory.
53
54
55 Internal fault - unused Consult factory.
56 General fault - caused by internal
problem or extreme environmental
condition
Check the environment for electrical
noise sources or interfering light sources.
Or consult factory.
57
58
59 Check environment for excessive
vibration or shock.
60 Invalid configuration in unit Reconfigure unit or double check current
configuration.
72 Incorrect number of active zone set
select inputs (hard fault code after
diagnostic code 70 above persists for
more than 10 minutes)
Check zone set select input wiring and
zone configuration selection.
73 Invalid or undefined zone set select input
combination, but correct number of active
zone set select inputs. (hard fault code
after diagnostic code 71 persists for more
than 10 minutes)
Check zone set select input wiring and
zone configuration selection.
74 Standby input or zone set select inputs
voltage too high
Check zone set select inputs or standby
input wired at more than system power
(24 VDC).
75 Scanner chassis connected to power (24
VDC)
Scanner chassis should be grounded to
0 VDC
82 Window not detected or entire dust
detection surface is dirty or blocked.
Check that the window is properly
mounted and clean the dust detection
surface.
90 Internal temperature fault The scanner internal temperature
exceeds the operating limit. Add more
ventilation.
