21
OS32C
User’s Manual
Chapter2
Operating States & Output Modes
E
NOTE: If the unit enters a fault state, all outputs will be OFF, except in Lockout Information Mode.
Table2-8 Output Polarity
Output Mode Active ON *1 Active OFF *2
Disabled Output always OFF Output always OFF
Safety Output Information Mode Same as OSSDs (output ON when safety
zone is clear)
Opposite of OSSDs (output OFF when
safety zone is clear)
Lockout Information Mode Output ON when fault occurs Output OFF when fault occurs
Warning Zone 1 Information Mode Output ON when zone 1 infringed Output OFF when zone 1 infringed
Warning Zone 2 Information Mode Output ON when zone 2 infringed Output OFF when zone 2 infringed
Window Contamination Warning Mode Output ON when window contaminated Output OFF when window contamined
*1. When the polarity is Active ON, the output modes will be active when the outputs are ON.
*2. When the polarity is Active OFF, the output modes will be active when the outputs are OFF.
