7 Tag Data Link Functions
7-18
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
7-2 Setting Tag Data Links
Additional Information
You can also use the Sysmac Studio to set the tag data links. Refer to A-2 Use the Sysmac Stu-
dio to Set the Tag Data Links (EtherNet/IP Connections) for details on setting the tag data links in
the Sysmac Studio.
Tag data links are set from the Network Configurator. Use the following procedure to start the Network
Configurator.
 Using the Windows Start Menu
To start the Network configurator, select OMRON - Sysmac Studio - Network Configurator for
EtherNetIP - Network Configurator from the Windows Start Menu.
When the Network Configurator starts, the following window is displayed.
7-2-1 Starting the Network Configurator
Procedure
