A-5
Appendices
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
A-2 Use the Sysmac Studio to Set the Tag Data Links (EtherNet/IP Connections)
A
A-2-2 Procedure to Make the EtherNet/IP Connection Settings with the Sysmac Studio
*1 Variables with its Network Publish attribute set to Output or Input in the Global Variable Table are called net-
work variables.
A-2-2 Procedure to Make the EtherNet/IP Connection Settings with the
Sysmac Studio
1 Registering devices
• Main Window
Register devices with which the EtherNet/IP connec-
tions are established to the project.
Setup Window
2 Creating network variables(*1)
... Refer to Registering the Net-
work Variable for the Origi-
nator Device on page A-12.
Global Variable Table on the
Sysmac Studio
3 Registering tags and tag sets
... Refer to Registering the Tag
and Tag Set on page A-14.
EtherNet/IP Connection Set-
tings (Tag Set Display)
Register the network variables that are set in step 2 as
tags and tag sets.
4 Setting Connections
... Refer to Setting Connections
for the Originator Device on
page A-17.
EtherNet/IP Connection Set-
tings (Connections Display)
Specify devices (i.e., target devices and originator
devices) and tag sets to communicate with using the
EtherNet/IP connections.
5 Going online from the Sysmac
Studio
... Refer to Transferring the
Connection Settings Data on
page A-29.
• Main Window
6 Downloading EtherNet/IP con-
nection settings
Note Connections automatically
start after the download.
... Refer to Transferring the
Connection Settings Data on
page A-29.
• Synchronization Window /
Transfer to Controller Dia-
log Box
• EtherNet/IP Connection
Settings
7 Checking operation
Stopping and starting connections
... Refer to A-2-5 Checking
Communications Status with
the Sysmac Studio and Trou-
bleshooting on page A-34.
EtherNet/IP Connection
Monitor Tab Page
