NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
This section describes the screen configuration for EtherNet/IP connection settings.
 Screen Transitions in the EtherNet/IP Connection Settings
• Connection Settings
• Transferring connection settings to the Controller from the computer
Precautions for Correct UsePrecautions for Correct Use
To transfer only the connection settings, execute Transfer from the EtherNet/IP Connection Set-
ting Tab Page.
The connection settings are not transferred from the Synchronization Window, the Transfer to
Controller Dialog Box, and the Transfer from Controller Dialog Box, even if you clear the Do not
transfer the connection setting Check Box, as long as the data in the computer and in the Con-
troller is the same.
A-2-3 EtherNet/IP Connection Settings
Select EtherNet/IP Connection Settings from the Tools Menu.
Double-click or right-click the
device to set and select Edit
from the menu.
EtherNet/IP Connection Settings (Tag Set Display)
Use the tab icons to switch
between displays .
EtherNet/IP Connection Settings
(Connection Display)
Right-click the device to set
and select Monitor from the
menu.
EtherNet/IP Device List Tab Page
EtherNet/IP Connection Monitor Tab Page
Select Synchronization
from the Controller Menu.
Select Transfer - To Controller
from the Controller Menu.
Select EtherNet/IP Connection
Settings from the Tools Menu to
display the device list. Right-
click the device and select Edit
from the menu.
Synchronization Window
Transfer to Controller Dialog
Box
EtherNet/IP Connection
Setting Tab Page
