8 CIP Message Communications
8-50
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
This object is used to read and write settings such as the IP address, subnet mask, and default gate-
way. For an NX701 CPU Unit, it is necessary to use the route path of the CIP communications com-
mand (the RoutePath in-out variable) to specify the port number (1 or 2) of the built-in EtherNet/IP port
to access.
Specify the service to execute with the service code.
Specify F5 hex.
Specify 00 or 01 hex.
00: Specify the class
01: Built-in EtherNet/IP port
The attribute ID specifies the information to read.
 Class Attribute ID
The class attribute ID specifies the attribute of the entire object.
8-5-3 TCP/IP Interface Object (Class ID: F5 hex)
Service Codes
Service
code
Parameter name Description
Supported services
Classes Instances
01 hex Get_Attribute_All Reads the values of the attributes. Sup-
ported.
Not sup-
ported.
0E hex Get_Attribute_Single Reads the value of the specified attribute. Sup-
ported.
Sup-
ported.
10 hex Set_Attribute_Single Writes a value to the specified attribute. The built-in EtherNet/IP port
restarts automatically after the value is written to the attribute. When
the restart process is not completed and the next Set_Attribute_Single
is executed, the general status “0C hex” (Object State Conflict) is
returned.
Not sup-
ported.
Sup-
ported.
Class ID
Instance ID
Attribute ID
Attribute ID Parameter name Description Attribute
Read data
Data
type
Value
01 hex Revision Revision of the object Read UINT
0001 hex: Unit version 1.01 or earlier
0002 hex: Unit version 1.02 to 1.09
0003 hex: Unit version 1.10
0004 hex: Unit version 1.11 or later
02 hex Max Instance The maximum instance number Read UINT 0001 hex
03 hex Number of Instances The number of object instances Read UINT 0001 hex
